dIsasseMBly of HousIng
dIsMount pedal Cranks
• Carefully lift the protective cover o the crank, using a
small at screw driver.
• Plug the extractor (P/N 2005737-001) onto the screw
of the crank
• Loose the screw with an open ended wrench (17 mm)
• Remove the screw and the lock washer
• Turn the extractor and screw it strongly into the
winding of the crank screw
• Use an open ended wrench (17 mm) to remove the
crank by screwing the bolt onto the axis.
