GE eBike BASIC - Alignment Ouput: Analog Diastole“; Alignment Ouput: RPM“; Alignment Output: ECG“




2018112-069 Rev. F eBike II, eBike II L, eBike II EL - 57 -
OUTPUT 4 Diastole
GAIN 1000 mV
GAIN 100 mmHg
ENTER
alIgnMent „ouput: analog dIastole“
The output voltage representing the diastolic value is
dened with this setting.
It is possible to adjust the voltage and / or the diastolic
value.
The setting is performed as described above under
Alignment „Ouput: Analog Load value“
Setting range:
GAIN (voltage): 500 to 2000 mV in
2 mV steps
GAIN (diastole): 50 to 250 mmHg in
5 mmHg steps
alIgnMent „ouput: rpM“
The output voltage representing the actual rpm value is
dened with this setting.
It is possible to adjust the voltage and / or the rpm value.
The setting is performed as described above under
Alignment „Ouput: Analog Load value“
Setting range:
GAIN (voltage): 200 to 1000 mV in
2 mV steps
GAIN (rpm): 30 to 130 rpm in
5 rpm steps
alIgnMent „output: eCg“
(For eBike II REHA Ergometer with integrated ECG amplier
only)
The zeroline and the amplitude of the analog ECG output
signal is dened.
The setting is performed as described above under
Alignment „Ouput: Analog Load value“
Setting range:
ZEROLINE: 200 to 10000 mV
in 10 mV steps
AMPLITUDE 200 to 10000 mV
in 10 mV steps
OUTPUT 5 rpm
GAIN 1000 mV
GAIN 50 rpm
ENTER
OUTPUT 6 EKG
ZEROLINE 5000 mV
AMPLITUDE 5000 mV
ENTER
