GE eBike BASIC - Electrical Safety

- 80 - eBike II, eBike II L, eBike II EL 2018112-069 Rev. F
eleCtrICal safety
Current leakage test results meet requirements?
Perform electrical safety checks when indicated.
All indicated electrical safety checks require a pass/fail indication for steps performed.
Record the measurement values in your debrief.
Step Condition
(1)
UUT - ON
(2)
Result Leakage
Current limits
Earth Leakage Current
1. Forward Polarity N/A
2. Neutral open, Forward Polarity N/A
3. Neutral open, Reverse Polarity N/A
4. Reverse Polarity N/A
Enclosure Leakage Current
1. Forward Polarity NC __________ μA Pass/Fail 100 μA
2. Neutral open, Forward Polarity SFC __________ μA Pass/Fail 500 μA
3. Ground open, Forward Polarity N/A
4. Ground open, Reverse Polarity N/A
5. Neutral open, Reverse Polarity SFC __________ μA Pass/Fail 500 μA
6. Reverse Polarity NC __________ μA Pass/Fail 100 μA
Patient Leakage Current to Ground (3)
1. Forward Polarity NC __________ μA Pass/Fail 100 μA
2. Neutral open, Forward Polarity SFC __________ μA Pass/Fail 500 μA
3. Ground open, Forward Polarity N/A
4. Ground open, Reverse Polarity N/A
5. Neutral open, Reverse Polarity SFC __________ μA Pass/Fail 500 μA
6. Reverse Polarity NC __________ μA Pass/Fail 100 μA
Ground Continuity Resistance
1. AC mains power cord ground prong to
exposed metal surface (ground lug)
N/A
(1) NC = Normal Condition
SFC = Single Fault Condition
N/A = Not Applicable
(2) UUT = Unit Under Test
(3) Test applies for eBike II basic/comfort with bloodpressure unit only - measuring point is the microfone connector
