GE eBike BASIC - Leg Rest Installation (Option)

2018112-069 Rev. E eBike II, eBike II L, eBike II EL - 229 -
1 2 3 4
6
a
6B
7
8
5
eBike II L / EL - uncrating instructions - 223 -
leG rest installation (oPtion)
• Necessary tools:
- Philips screwdriver
- Allen key 6 mm (metric)
- pipe wrench
• Contents of the set:
[1] [2] 2 leg rests
[3] 2 spacing plates
[4] 4 special thread washer
[5] 4 washer Ø 8,4 x 16
[6A] 4 screw M8x70 with hexagon socket (eBike EL)
[6B] 4 screw M8x50 with hexagon socket (eBike L)
[7] 1 retaining clamp for leg rests with 2 screws
[8] 1 installation instruction
- 222 - eBike II L / EL - uncrating instructions
