GE eBike BASIC - Removing the Transport Lock (Ebike el Only); Power and ECG Connections

2018112-069 Rev. E eBike II, eBike II L, eBike II EL - 227 -
eBike II L / EL - uncrating instructions - 221 -
removinG the transPort loCk
(eBike el only)
• The transport lock is xed to the base frame with
2 screws (17 mm).
Unscrew carefully both screws with a wrench and
remove the transport lock.
• Keep the transport lock and xing screws,
because the transport lock must be reinstalled
before transporting the ergometer.
Power and eCG ConneCtions
• Refer to the eBike EL user manual for installation
of the power cable and ECG connection.
- 220 - eBike II L / EL - uncrating instructions
• Unpack the paper roll and insert it in the holder.
settinG uP the eBike el
• Move the eBike EL to the nal location and apply
the castor brakes.
• Adjust the screw foot at the outrigger until it is
at on the oor..
