reMove ConneCtIon Box
• Remove 6 xing screws.
!! Support the connecting box from below !!
• Disconnect the connecting cable to the mains switch
at the modular connector (a).
• Disconnect the connecting cable LRE <-> BKE from
the LRE board (CAT-5 Patchkabel)
• The connecting box can be removed.
