GE eBike BASIC - Static Load Calibration; Dynamic Load Cal.; Software Update



- 50 - eBike II, eBike II L, eBike II EL 2018112-069 Rev. F
statIC load CalIBratIon
The static calibration of the load unit is described in the
separate chapter „Calibration / alignment“.
dynaMIC load Cal.
To perform a dynamic load calibration, a calibrated
dynamic test bench is needed.
The dynamic calibration of the load unit is described in the
separate chapter „Calibration / alignment“.
software update
For a description of a software update of the ergometer
(rmware) see the separate chapter „Software update“.
Baudrate 8n2
The baudrate can be selected between 1.200 Baud and
115.000 Baud.
Default value for standard ergometers is 4.800 Baud.
Select the desired parameter by use of the right and left
softkeys (↑ ↓) and conrm with ENTER.
eCg startpulse
To congurate the remote start pulse for external ECG
recorders (ergometer is controlled by internal programs).
Select the desired parameter by use of the right and left
softkeys (↑ ↓) and conrm with ENTER.
Adjust the appropriate valuewith the arrow keys and store
the value with ENTER.
Leadtime
Remote pulse leadtime before the next load step
Setting range: 1 to 30 sec. in 1 sec. steps
Pulsewidth
Remote pulse pulse width
Setting range: 100 to 1000 ms in 100 msec steps
Selection of Serial baudrate
Baudrate 8N2
1.200
2.400
4.800
9.600
19.200
ENTER
configuration of ecg reMote pulSe
ECG - Startpulse
Leadtime
10 sec
Pulsewidth
100 msec
ENTER
Hint
• The baudrate must be set to 4800 baud always!
