GE eBike BASIC - Wiring Diagram Ebike II L with BCU

wIrIng dIagraM eBIke II l wItH BCu
E F G H A B C D
5 6 7 8 1 2 3 4
Strain gauge
red (rot) green (grün) blue (blau) black (schw.)
Drive unit
Control terminal
red (rot)
blue (blau)
Modular connector
Power supply
Eddie current brake
LRE PCB
RJ-45 RJ-45 RJ-45
RS-232
RJ-45
X11
brown/white
patch cable BLACK
BKE module (interface)
patch cable RED (RS-232)
RJ-45
X16
Power switch
Modular connector
Power input
EC / G
B / F
PE
A D / H
1 5 2 (PE)
3 4
Motor control
Saddle motor
Motor longitudinal
Remote control
786 (PE)
2 1
2 1
DSUB connector
2018112-069 Rev. F eBike II, eBike II L, eBike II EL - 23 -
