GE eBike BASIC - NIBP Test


- 72 - eBike II, eBike II L, eBike II EL 2018112-069 Rev. F
All the dierent components are connected with tubes
(one pressure system) and connected to the cu connector
of the ergometer control terminal (use cu adaptor).
nIBp test
This function is used to check the internal pressure system
(pressure sensor, closeness, leakage etc.).
Select „NIBP Test“ in the service menu and conrm with
ENTER (or SELECT).
Using the hand pump, apply a xed pressure to the system
The actual pressure value is displayed.
Compare the displayed ergometer value with the value of
the manometer.
The maximum allowed deviation is +/- 3mmHg.
compensating container manometer
hand pump
calibration Setup nibp
teSt of the internal nibp preSSure SySteM
NIBP Test
NIBP pressure
123 mmHg
CLOSE VALVE
Hint
• If the applied pressure reaches 320 mmHg, the internal
safety valve is opened.
Press „Close valve“ (middle soft key) to continue with the
NIBP-Test.
