2018112-069 Rev. F eBike II, eBike II L, eBike II EL - 149 -
2018111-149
1x drive unit eBike II, assembled
6x screw M8x20
6x star washer 8.4x15x0.8
SPARE EBIKE II DRIVE UNIT
Service Kit: drive unit, new, for eBike II
2018111-029
2x combi-slotted screw M8x1x18
2x lock washer
2x cap for crank thread
SPARE EBIKE SCREW SET FOR CRANKS
Service Kit: screw set for pedal kit
2018111-302
1x pedal, E 10, left and right, with rubber strap
SPARE EBIKE II III PEDAL SET R/L LARGE
Pedal set
2018111-301
1x crank, left, square, 170 mm
1x crank, right, square, 170 mm
1x pedal, E 10, left and right, with rubber strap
2x combi-slotted screw M8x1x18
2x lock washer
2x cap for crank thread
SPARE EBIKE II III CRANK/PEDAL SET R/L
Pedal set, left and right, cranks and pedals
