2018112-069 Rev. F eBike II, eBike II L, eBike II EL - 63 -
• For safety reasons, a tilt protection has to be mounted
(marked 5 / 5).
• The static calibration with 8kg weight can be
performed.
unlIftIng tHe ergoMeter
• Dismount the tilt protection (5 / 5).
• Carefully lift the lever arm of the main support frame
whilst holding the ergometer at the handle bar, until
the ergometer chassis stands stable on the oor and
the front support.
• Disassemble the lift tool in reverse order.
ergoMeter in lift-up poSition with tilt protection Mounted
Warning
If the ergometer is lifted up, the tilt protection has always to be
mounted and secured!
