2018112-069 Rev. F eBike II, eBike II L, eBike II EL - 65 -
• With the aid of an assistant, lift the couch ergometer
eBikeL / EL at the back of the base and position the
calibrationstay labelled „rear“ (see d. in illustration)
to the right of the center brace below the transverse
frame.
• Attach the calibration stay to the base, using adhesive
tape (see e. in illustration).
• Lift the base a little and wait for the calibration stay to
stop swinging.
• With the aid of the calibration stay, align the bottom
edge of the connection box exactly horizontal.
• To do so, open clamping lever g and adjust top
section.
• Perform calibration (see following section)
Caution
• Place a weight (e.g. the tool chest) on the baseplate
of the calibration stay.
• Make sure that both sides of the transverse frames it in
the calibration stay and that the stay itself is in a stable
position
