DIRECTION 2286865, REVISION 14 LOGIQ™ 7 SERVICE MANUAL
5-4 Section 5-2 - Hardware Compatibility Matrix
5-2-1-3 OP Panel and Keyboard
Figure 5-28 OP Panel and Keyboard- FRU Compatibility
R8.0.x R8.0.x R8.0.x R8.0.x
Latest Software
SW Upgraded BT09 (w BT02/BT03 console)
SW Upgraded BT09 from BT04/BT06/BT07
19 inch LCD Upgraded BT09 from 17 inch LCD
R8.0.X (BEP4)
comment
2267259-2 P9534XA KEYBOARD ASSY Y NNN
2299453
P9536AG OP PANEL A/N KEYBOARD
ASSY
Depends NNN
Replaceable only on KBD 2267259 and
2267259-2
2306274
P9536AR OP PANEL KEY
ACCESSORY SET
Depends NNN
Replaceable only on KBD 2267259 and
2267259-2
2299448
P9536AB OP PANEL ENCODER
ASSY
Depends NNN
Replaceable only on KBD 2267259 and
2267259-2
2306270 P9536AP OP PANEL CONTROL Depends NNN
Replaceable only on KBD 2267259 and
2267259-2
2299447 P9536AA OP PANEL LCD UNIT Depends NNN
Replaceable only on KBD 2267259 and
2267259-2
2306273 P9536AQ OP PANEL KEY SWITCH Depends NNN
Replaceable only on KBD 2267259 and
2267259-2
2299452 P9536AF OP PANEL TGC ASSY Depends NNN
Replaceable only on KBD 2267259 and
2267259-2
2299451
P9536AE OP PANEL TRACKBALL
ASSY
Depends N N N Replaceable on any KBD
2344632-2 P9534XK KEYBOARD ASSY Y NNN
2369818 P9536BG A/N KBD ASSY Depends YYY
Replaceable only on KBD 2344632,
2344632-2
,5138507, 5138507-2
2369816 P9536BR KEY ACCESSORY Depends YYY
Replaceable only on KBD 2344632,
2344632-2,5138507, 5138507-2 Contains
A/N Key Tops
Clear Caps
Labels for clear caps
Knobs for rotally encoders
TGS Slid Caps
236981
6-2
P9536BR KEY ACCESSORY Depends YYY
Replaceable only on KBD 2344632,
2344632-2,5138507, 5138507-2 Contains
A/N Key Tops
Clear Caps
Labels for clear caps incl.4D
Knobs for rotally encoders incl.4D
TGS Slid Caps
2369826 P9536BB ROTARY ENCODER ASSY Depends YYY
Replaceable only on KBD 2344632,
2344632-2,5138507, 5138507-2
2369817 P9536BP I/F BOARD ASSY Depends YYY
Replaceable only on KBD 2344632,
2344632-2,5138507, 5138507-2
2369825 P9536BA LCD UNIT NNNN
Replaceable only on KBD 2344632,
2344632-2,5138507, 5138507-2
2369815 P9536BQ SW BOARD ASSY v YYY
Replaceable only on KBD 2344632,
2344632-2,5138507, 5138507-2
2369822 P9536BF TGC ASSY Depends YYY
Replaceable only on KBD 2344632,
2344632-2,5138507, 5138507-2
2369823 P9536BE TRACKBALL ASSY Depends YYY Replaceable on any KBD
2344632-3 P9534XK KEYBOARD ASSY YYNN
2369825(TouchPanel) cannot be
assembled on 2344632-3.
5138507-3 SVC KEYBOARD LOGIQ7 YYYYCost reduction from previous KBD
2301857 P9536SD LAMP ASSY Y NNN
5117796 LAMP STAY ASSY OPA L7 N YYY
2301853-4 P9536RB TASK LAMP ASSY YYYY
2357676 P9536RK LIGHT BULB YYYYLight Bulb only (lower level of 2301853-4)
5117485 ? FCON Cable Assy
N YYY
5117795 ? FOOT SW Bracket ASSY
N YYY
FRU Part# Description
FRU compatibility
BT09
～
