GE HEALTHCARE
DIRECTION 2286865, REVISION 14 LOGIQ™ 7 SERVICE MANUAL
Section 6-6 - BW Printer Setting / Adjustment 6-31
6-6-4 Service Tips - Print Speed
1.) Make sure that the UP-D897 is switched ON. (The back light of the LCD light is in green.) If not,
press the ON/OFF switch.
2.) Confirm that “READY” is displayed on the LCD, then press
the jog dial.
The UP-D897 enters the menu mode. When you perform a menu operation for the first time
after you purchase the unit , the top item of the “BEEP” menu will be displayed. If you already
have performed a menu operation, the items that you set last is displayed.
NOTICE
Problem:
Compared to the UP-D895, it takes a few seconds longer for the UP-D897 to receive data from L7
system. All that time, an user cannot operate the L7 system and must wait until the UP-D897 finished
receiving data from the L7.
Cause:
This is due to driver software difference between UP-D895 and UP-D897. It seems the UP-D897 driver
software has been modified from the UP-D895.
Solution:
The following actions must be required:
• UP-D897 printer: Change from UP-D897 to UP-D895 on “COMD” menu using the printer jog
dial. This solution allows the UP-D897 to be configured to use the UP-D895 interface and driver.
When the “COMD” is selected to “CO:895”, the response time becomes the same as the UP-
D895. Perform this section.
• LOGIQ7: Change from UP-D897 to UD-D895 using Connectivity > Service > BW Printer to
use UP-D895 driver software.
Jog Dial
(PRESS)
READY
To Next Page
