GE HEALTHCARE
DIRECTION 2286865, REVISION 14 LOGIQ™ 7 SERVICE MANUAL
9-42 Section 9-9 - Renewal Parts List For BT04 and BT06
9-9-13 HDD and Battery
Figure 9-12 HDD and Battery
Table 9-32 HDD and Battery
Item Part Name Part Number Description Qty FRU
550 BECOMPSW3 SVC CSL L7 5119906-3
Obsolete, Replaced by 5119906-4. Do NOT use this
parts!
11
550 BECOMPSW3 SVC 5119906-4
See Reuse Parts List below.
11
- CPU Battery -
Included on the CPU Board.
Type: CR2032, Lifetime: Approx. 10 years
1N
551 USB MODEM 5120503 USB modem (Option) 1 1
552 UPS BATTERY PACK 2304809-2 battery of ATX power supply 1 1
553 DGPCIO/VIC2-SVC 5133526 1 1
554 EXTENDED MEMORY3 L7 5118511 Option. - 2
555 HD L7 5118510
80GB, Installed in the PC box.
11
LEFT
550
551
552
553
554
555
556-1
556-2
557
To Next Page
