GE LOGIQ 7 Service Manual
4
of 1
of 1 rating
394 pages
Give review
Manual
Specs
To Next Page
To Next Page
To Previous Page
To Previous Page
Loading...
GE H
EALTHCARE
D
IRECTION
2286865, R
EVISION
14
LOGIQ™ 7 S
ERVICE
M
ANUAL
6-40
Section 6
-8 - Jumper and
Dip Switch S
etting
6-8-3-2
Accessing Dip Switch Module for inspection
1.)
Remove th
e two sc
rews of RS2
32C boa
rd plate.
2.)
Remove th
e RS232
C board from
the VCR
to acces
s the dip
switch.
Figure 6-52 Opening Board Plate
Figure 6-53 Removing Board
Screws
RS232C
board plate
Dip Switch
RS232C Bo
ard
201
203
