GE LOGIQ 7 Service Manual

GE HEALTHCARE
DIRECTION 2286865, REVISION 14 LOGIQ™ 7 SERVICE MANUAL
6-6 Section 6-3 - Caster Brake/Swivel Function Adjustments
6-3-1 Brake Function Adjustment (cont’d)
3.) After completion of adjustment, press on the brake and check its function and location of the boss,
connected to the caster lock arm.
Figure 6-6 Brake Function Check
Example: GOOD
Boss of the front caster in place, and brake
properly adjusted.
Example: NO GOOD
Boss of the front caster NOT in place, and brake
NOT properly adjusted.
