GE LOGIQ 7 Service Manual

GE HEALTHCARE
DIRECTION 2286865, REVISION 14 LOGIQ™ 7 SERVICE MANUAL
Section 8-2 - Software Loading Procedures for BT09 (R8.x.x or later) 8-21
8-2-8-4 LAN Parameter Setting
1.) On the desktop, left-click on My Network Places, then right-click on Properties...
2.) Verify that two network icons appears. (If “Local Area Connection” icon does not appear, the
hardware failure might occur.)
3.) Using the right trackball button, double-click on Local Area Connection.
4.) When the following window appears, it will be automatically closed later.
5.) When the following window appears, right-click on Cancel.
6.) Close all windows.
Figure 8-73 Properties
Figure 8-74 Local Area Connection
Figure 8-75 Cancel
