GE HEALTHCARE
DIRECTION 2286865, REVISION 14 LOGIQ™ 7 SERVICE MANUAL
Section 3-1 - Overview 3-9
3-2-5 LCD Monitor Removal Caution
3-2-6 Shipping Delivery Requirements
Do NOT hold the scanner at the LCD monitor or rotaing arm using the belt as shown. Always hold it at
the body part of the console.
CAUTION
Always lock the LCD monitor arm before removing the LCD monitor. This prevents the monitor
arm from being suddenly and fastly extended when removing the LCD monitor. Failure to heed
this warning may result in personal harm, harm to others or death.
Figure 3-4 Shipping Delivery Requirements
Arm Lock (LCD Model ONLY)
CAUTION
Always hold the scanner
at the body.
To Next Page
