GE LOGIQ 7 Service Manual

GE HEALTHCARE
DIRECTION 2286865, REVISION 14 LOGIQ™ 7 SERVICE MANUAL
Section 2-2 - General Console Requirements 2-3
2-2-2 Electrical Requirements
2-2-2-1 Electrical Requirements
NOTE: GE Medical Systems requires a dedicated power and ground for the proper operation of its
Ultrasound equipment. This dedicated power shall originate at the last distribution panel before
the system.
Sites with a mains power system
with defined Neutral and Line:
The dedicated line shall consist of one phase, a neutral (not shared with any other circuit), and
a full size ground wire from the distribution panel to the Ultrasound outlet.
Sites with a mains power system
without a defined Neutral:
The dedicated line shall consist of one phase (two lines), not shared with any other circuit, and
a full size ground wire from the distribution panel to the Ultrasound outlet.
Please note that image artifacts can occur, if at any time within the facility, the ground from the
main facility's incoming power source to the Ultrasound unit is only a conduit.
2-2-2-2 LOGIQ™ 7 Power Requirements
The following power line parameters should be monitored for one week before installation. We
recommend that you use an analyzer Dranetz Model 606-3 or Dranetz Model 626:
2-2-2-3 Inrush Current
Inrush Current is not a factor to consider due to the inrush current limiting properties of the power
supplies.
2-2-2-4 Site Circuit Breaker
It is recommended that the branch circuit breaker for the machine be ready accessible.
Table 2-4 Electrical Specifications for LOGIQ™ 7
PARAMETER AREA LIMITS
Voltage Range
100V 100 VAC ±10% (90-110 VAC)
220V 220-240 VAC ±10% (198-264 VAC)
120V 120 VAC ±10% (108-132 VAC)
Power All applications MAX. 1200 VA
Line Frequency All applications 50/60Hz (±2Hz)
Power Transients All applications
Less than 25% of nominal peak
voltage for less than 1 millisecond for
any type of transient, including line
frequency, synchronous,
asynchronous, or aperiodic
transients.
Decaying Oscillation All applications
Less than 15% of peak voltage for
less than 1 millisecond.
CAUTION
POWER OUTAGE MAY OCCURE. The LOGIQ™ 7 requires a dedicated single branch circuit. To
avoid circuit overload and possible loss of critical care equipment, make sure you DO NOT have
any other equipment operating on the same circuit.
