GE HEALTHCARE
DIRECTION 2286865, REVISION 14 LOGIQ™ 7 SERVICE MANUAL
4-6 Section 4-2 - General Procedure
4-2-2-3 Entering Maintenance Mode (cont’d)
4-2-2-3-2 R 4.x.x to R6.0.x
1.) The Start Up Screen will be shown on the Monitor display when the system is turned ON.
2.) The “Probing for maintenance access” dialog appears. Enter Password, then click on OK.
3.) Then Start Loader display will be shown on the Monitor display.Click on Maintenance.
4.) Click on Exit to Windows in maintenace diaglog window.Then the scanner is booted up
automatically.
4-2-2-3-3 R2.x.x to R4.x.x
1.) Insert the service dongle in the Service port located at the rear panel.
2.) The Start Up Screen will be shown on the Monitor display when the system is turned ON.
3.) Then Start Loader display will be shown on the Monitor display. Then the scanner is booted up
automatically.
NOTE: To enter the Maintenance Mode, select Maintenance button.
NOTE: Start is selected automatically when it time out.
Figure 4-8 Clicking on Mainttenance
Figure 4-9 Start Application Window
