DIRECTION 2286865, REVISION 14 LOGIQ™ 7 SERVICE MANUAL
5-44 Section 5-8 - Monitor Video Specification
Section 5-8
Monitor Video Specification
5-8-1 Input
5-8-2 Outputs
5-8-2-1 SVGA
5-8-2-2 TV Format
5-8-2-3 PAL BDGHI
Standard Format Signal Sync DDC Termination
SVGA 800 x 600 / 75 Hz RGB: 0 - 700 mV
H: TTL
V: TTL
VESA DDC2
signals
75 ohms
Standard Format Signal Sync DDC Termination
SVGA 800 x 600 / 75 Hz RGB: 0 - 700 mV
H: TTL
V: TTL
VESA DDC2
signals
75 ohms
Type Standards Termination
SVHS
NTSC EIA and
PAL BDGHI
75 ohms
Composite
Video
NTSC EIA and
PAL BDGHI
75 ohms
RGB
NTSC EIA and
PAL BDGHI
75 ohms
B&W
NTSC EIA and
PAL BDGHI
75 ohms
General SVHS-luma SVHS-croma Composite RGB B&W
Line/field: 625/50
FH: 15625 Hz
FV: 50 Hz
Bandwidth: 6MHz
(luma)
Signal: 100 IRE
100% amplitude
Sync: 43 IRE
Burst amplitude:
+/- 21.5 IRE, 10
cycles
Fsc: 4.43361875
MHz 100%
saturation
Summed luma
and croma
Signal: 0-700
mV
Comp sync/H
sync/ V sync: 0.3
- 4 Vpp
SVHS luma
