1-14 Section 1-2 - Important Conventions
1-3-6 Label Locations (For BT04, BT06, and V65x)
NOTE: For the symbols shown in the illustration below, refer to previous pages in this chapter.
1.) Possible Shock Hazard
2.) Caution for devices near by the equipment
3.) Caution for Transportation
4.) Prescription Devices (For USA Only)
5.) CE Marking of conformity and WEEE mark
6.) CISPR
7.) Voltage Range
8.) Signal Ground Point Label
9.) Power Indication Label
10.)Caution for Grounding Reliability (For USA, Canada and Japan)
Figure 1-2 OUTSIDE MARKINGS OF LOGIQ™ 7 For BT04
or later (Back Side)
1.
3.2.
4.
5.
6.
7
9.
8.
7.
10.
