DIRECTION 2286865, REVISION 14 LOGIQ™ 7 SERVICE MANUAL
3-16 Section 3-4 - Completing the Installation
NOTE: PES: Polyethersulfone NORYL: Modified Polyphenylene Oxide PU: Polyurethane
PBT: Polybutylene Terephthalate ABS: Acrylonitrile Butadiene Styrene
NOTE: Some probes indicated on the table above have two different part numbers. The upper row
shows the part numbers of probes for Japan. The lower row shows the part numbers of probes
for regions other than Japan. Probes which have only one part number are not available in
Japan.
The following transducers, additional to ones listed in Table 3-6, are supported by V65x and later LOGIQ
7 models.
The following transducers, additional to ones listed in Table 3-7, are supported by R7.5.x and later
LOGIQ 7 models.
The following transducers, additional to ones listed in Table 3-8, are supported by BT09 and later
LOGIQ 7 models.
4D10L PBD SUPERFICIAL LINEAR Volume H44801GB
5121651
KTZ156836
4C PBT ABDOMINAL CONVEX H4904PC
5131944
5123455
12L Noryl SUPERFICIAL LINEAR H40412LH
2295375
2295377
P2D ABS CARDIOLOGY CWD H4830JE TE100024
P6D --- SUPERFICIAL CWD H4830JG TQ100002
Table 3-6 List of Transducers supported by V65x and later
Probe Name
Material of
Headshell
Area of Using TYPE Catalog Number Part Number
9L PBT
VASCULAR SMALL
PARTS
LINEAR H40412LT 5131433
4DE7C PBT OB Gyn Urology CONVEX Volume H44801GA 5121650
Table 3-7 List of Transducers supported by R7.5.x and later
Probe Name
Material of
Headshell
Area of Using TYPE Catalog Number Part Number
3CRF PU: PolyUrethane ABDOMINAL MICRO-CONVEX H40442LP
5214820
5196216
Table 3-8 List of Transducers supported by BT09 and later
Probe Name
Material of
Headshell
Area of Using TYPE Catalog Number Part Number
11L PBT SUPERFICIAL LINEAR
H78842P
H40412LY
5251881
5171885
Table 3-5 List of Transducers supported (All models)
Probe Name
Material of
Headshell
Area of Using TYPE Catalog Number Part Number
