GE LOGIQ 7 Service Manual

GE HEALTHCARE
DIRECTION 2286865, REVISION 14 LOGIQ™ 7 SERVICE MANUAL
9-4 Section 9-3 - Renewal Parts List For BT09
7 Cable13 for BulkHead 5257231
Internal 26pin flat cable -between PCI-DGVIC2/
Bulkhead
11
8 Cable25 for BulkHead 5257233
Internal 50pin flat cable -between PCI-DGVIC2/
Bulkhead
11
9 SVP REAN4 PANEL 5314714 Metal plate with PCB board 1 1
10 SVP REAN4 USB CBL 5314713 USB Cables with metal plate 1 1
-
FRU Part LCD CABLE DUCT ASSY L7.
No RGB Cable
5309932
Main duct cable. This part same as previous duct
cable FRU 5117797 but without Analog RGB
signal BNC cables
1 1
11 DDBF128 ASSY CSL L7 5182379-2 1 1
12 EBUS4T ASSY CSL L7 5182215 1 1
13 EBUS4B ASSY CSL L7 5182757 1 1
14 Mitsubishi CP30DW COLOR PRINTER 5310492 For market globally 1 1
15
Mitsubishi CP30D COLOR PRINTER for
Japan
5310491 For use in Japan only 1 1
16 VCR MD-3000 JPN NTSC USB Control 5212446 For use in Japan only 1 1
17 VCR MD-3000 EURO PAL USB Control 5199397 For use in EU (or other areas with PAL system) 1 1
18 VCR MD-3000 USA NTSC USB Control 5213259
For use in USA Only (or other areas with NTSC
120V In/Out)
11
- R8.0.0 Application Software CD 5311031-3
R800 common software for both upgraded BT09
and pure BT09
11
- Ghost DVD for BEP4 5305206-3
Base image (Ghost) for pure BT09 (BEP4 system)
only
1 1
- Ghost DVD for BEP3 5191839-3
Base image (Ghost) for upgraded BT09 (BEP3
system)
1 1
Table 9-3 BT09 Parts
Item Part Name Part Number Description Qty FRU
