GE HEALTHCARE
DIRECTION 2286865, REVISION 14 LOGIQ™ 7 SERVICE MANUAL
Section 9-4 - Renewal Parts List For R7.5.x 9-7
6 DVI-HDMI ADAPTOR 5240848
DVI to HDMI conversion (For Upgraded Version
only)
11
- 19inch LCD ARM WITH CABLE ASSY 5245143
Obsolete. Use FRU 5264730 to upgrade this part
to -2 if stock remains.
--
7 19inch LCD ARM WITH CABLE ASSY 5245143-2
LCD arm with Cables assy. Improved rotational
limiter plate. For Korea console, Arm Joint (12(b))
must be re-used.
11
8 19 LCD DVI HDMI CABLE 5224943 Display Cable 1 1
9 19 LCD MIC SPK CABLE ASSY 5224944 Mic/Spk Cable 1 1
10 19 LCD POWER CABLE 5224942 48V Power Cable 1 1
11 ARM COVER LCD L7 5136256 Arm plastic cover / top 1 1
12 ARM JOINT COVER LCD L7 5136257
Arm plastic cover / joint. Common part between
17” and 19” LCD Monitor arm.
11
12
(b)
FRU ARM JOINT COVER LCD L7 FOR
KOREA
5271234
Physically the same as 5136257, but caution label
in Korean Lanugage.
11
13 19inch AC DC ASSY L7 5248134 48V Power Supply (Denotes ‘Returnable’) 1 1
14 19 LCD 48V UNIT CABLE 5224941 FCON2->48V Power Supply 1 1
Table 9-5 V75x Parts
Item Part Name Part Number Description Qty FRU
