DIRECTION 2286865, REVISION 14 LOGIQ™ 7 SERVICE MANUAL
9-18 Section 9-7 - Renewal Parts List For BT06-2 or later
9-7-2 BT06-2, LCD: Equipment Models Covered in this Chapter (LOGIQ 7)
Table 9-15 Material List
Part Name Part Number Quantity Description
OPERATOR CONSOLE ASSY 5176713 1 100V, NTSC
OPERATOR CONSOLE ASSY 5176888 1 1 120V, NTSC
OPERATOR CONSOLE ASSY 5176300 1 1 220V, PAL
OPERATOR CONSOLE ASSY 5176380 1 220V, NTSC
LOGIQ7 Application Software CD
R6.2.0
5174576 (Obsolete)
000000
LOGIQ7 Application Software CD
R6.2.2
5195941
111111
LOGIQ7 Ghost3 CD for BEP3,
R6.2.0
5174668-2
111111
L7 BT06-2 eDoc CD 5177295-200 111111
LOGIQLEAN MIDDLE 2369384 1
MSDS FOR KAO ACOUSTIC GEL 2384010 1
GEL AQUASONIC GEL U0403BD 11111
PARKER AQUASONIC100 2384142 11111
CD-R Media 700MB 5118386 111111
DVD-R 4.7GB 8 x Speed media 5160800-2 111111
KEY LABEL2 2360321 111111
LOGIQ 7 WEEE instruction 5143413 111111
WARRANTY CARD P9889AH 1
HIGHLIGHT DOC 5141402 1
SAFETY PAMPHLET 5118349 1
SAFETY PAMPHLET License 5123992 1
SFDA LABEL L7 5149899 1
AC CORD 100V JPN 2371416 1
AC CORD 100V USA 2371417 1 1
AC CORD 200V EU 2371418 1 1
AC CORD 200V CHIN 2371415-2 1
LOGIQ7 VER6 STYLE_F LCD JPN (5148051)
LOGIQ7 VER6 STYLE_F LCD USA (5148051-2)
LOGIQ7 VER6 STYLE_F LCD EU (5148051-3)
LOGIQ7 VER6 STYLE_F LCD KOREA (5148051-4)
LOGIQ7 VER6 STYLE_F LCD ASIA120 (5148051-5)
LOGIQ7 VER6 STYLE_F LCD ASIA220 (5148051-6)
