DIRECTION 2286865, REVISION 14 LOGIQ™ 7 SERVICE MANUAL
Section 9-9 - Renewal Parts List For BT04 and BT06 9-39
9-9-11 OP Panel and Keys (cont’d)
Table 9-30 OP Panel and Keys
Item Part Name Part Number Description Qty FRU
401 KEYBOARD ASSY 5138507-2
whole keyboard, this includes next 7 items (Items 403
~ 409) (Obsolete, Replaced by 5138507-3)
11
401 SVC KEYBOARD L7 5138507-3
whole keyboard, this includes next 7 items (Items 403
~ 409)
11
403 ROTARY ENCODER ASSY 2369826
OBSOLETE
Three rotary encoders with cables. Three groups of
encoders with cables and metal stay. In total, there
are 14 encoders in this FRU.
11
403 ROTARY ENCODER ASSY 2369826-2
Three rotary encoders with cables. Three groups of
encoders with cables and metal stay. In total, there
are 14 encoders in this FRU. This version contains
two types of LCD brightness adjustment knob and
instruction.
1 1
404 TRACKBALL ASSY 2369823 trackball, two cables w/o bracket 1 1
405 TGC ASSY 2369822 TGC PCB Assy, bracket, cable w/o TGC knobs 1 1
406 A/N KBD ASSY 2369818 board of a/n key switch 1 1
407 I/F BOARD ASSY 2369817 I/F PCB ASSY, Mic cable, USB cable 1 1
408 SW BOARD ASSY 2369815 Three SW PCB Assy, rubber sheets, two cables 1 1
409 KEY ACCESSORY SET 2369816
A/N keytops, all encoder knobs, all clear key caps,
labels (For knob repair, order 2363861 repair kit.)
1 2
410 TASK LAMP ASSY 2301853-4 L7 Pro does not support the task lamp. 1 1
411 LAMP STAY ASSY 5117796 Stay and cable (inside L7) 1 2
412 TASK LAMP KNOB 2304620 knob 1 2
413 LIGHT BULB 2357676 BULB ONLY 1 1
414 CAP 2239428 CAP for Hole 1 2
- KEY LABEL 2360321 Label for clear key top 1 2
- AN KEY TOP NORWEGIAN 5125104 Option 1 2
- AN KEY TOP SWEDISH 5125100 Option 1 2
- AN KEY TOP GREEK 2375160 Option 1 2
- AN KEY TOP RUSSIAN 2375159 Option 1 2
