GE HEALTHCARE
DIRECTION 2286865, REVISION 14 LOGIQ™ 7 SERVICE MANUAL
Section 9-9 - Renewal Parts List For BT04 and BT06 9-45
9-9-14 Power Units (cont’d)
Table 9-33 Power Units
Item Part Name Part Number Description Qty FRU
701 SSR ASSY 5117726 SSR + CONNECTOR PCB 1 1
702 FUSE HOLDER ASSY 5117727 Without fuse 1 1
702-
1
FUSE 2315585 F1, 200V, T12V 1 1
- LV -04 UNIT 5118824
Obsolete. Cannot use this part any longer, and the
parts in stock have been purged.
- -
703 LV UNIT ASSY MAIN PS L7 5118824-2 low voltage regulator + Cable 1 1
704 HV UNIT 2372387
high voltage regulator (Half height),
including materials used when changing Full height
HV unit to the Half height.
1 1
706 AC CORD 100V US 2371417 power cable of 100V, with clamp 1 1
706-
2
AC CORD 100V JPN 2371416 For JAPAN, power cable of 100V, with clamp 1 1
706-
3
AC CORD 200V EU 2371418 power cable of 200V, with clamp 1 1
706-
4
AC CORD 200V China CCC 2371415-2 applied to Chaina CCC specifications 1 1
708 MAIN Transformer 2373331-2 power transformer 1 1
707 NF INLET Assy 5117723 Noise Filter + Inlet PCB 1 1
705-
1
AC IN-OUT 100V 5117724 1 1
705-
2
AC IN-OUT 200V 5117725 1 1
705-
3
AC IN-200V OUT-100V 5118052 For Korea 1 1
711 Connector Assy 5117728 1 1
709 CONSOLE FAN ASSY2 5117493 3 fans for BT04, BT06 1 1
709 CONSOLE FAN ASSY A 5122614 For upgrade BT04, upgrade BT06 1 1
- AIR FILTER A 5112530 UNDER NEST 1 2
- AIR FILTER B 5112531 UNDER PC BOX 1 2
- AIR FILTER C 5115806 UNDER RATING PLATE 1 2
- SSR-HLV CABLE 5119119 CB107 1 1
- SSR-AC PANEL CABLE 5119120 CB109 1 1
- VOLTAGE SEL CABLE 5119121 CB108 1 1
- FAN CABLE BRAKET ASSY 5117491 1 1
- AC Cord UK & Ireland 5151455 1 2
- AC Cord Denmark 5151457 1 2
