GE LOGIQ 7 Service Manual

GE HEALTHCARE
DIRECTION 2286865, REVISION 14 LOGIQ™ 7 SERVICE MANUAL
Section 9-9 - Renewal Parts List For BT04 and BT06 9-55
9-9-17 LCD Option (cont’d)
Table 9-37 LCD Option
Item Part Name Part Number Description Qty FRU
901 17 inch LCD MONITOR ASSY 5169935-2
Monitor, not inclucing the following parts (102, 103,
and 105)
11
902 PANEL FRONT LCD L7 5132572 1 2
903 PANEL REAR LCD L7 5132573 1 2
904 COVER VESA LCD L7 5132574
Rear VESA cover of 17” LCD monitor use for globally
except for Korea.
1 2
904
(b)
FRU VESA COVER L7 17INCH FOR
KOREA
5265097
Physically the same as 5132574, but with Korean
caution Label.
1 2
905 SWITCH MIC_ASSY LCD_MONITOR 5137744 Set of SWITCH and MIC 1 1
906 SPEAKER SET (L&R) LCD L7 5132576 Including left and right speakers 1 1
907 LCD D-SUB CABLE ASSY CSL L7 5125391 DVI Cable from BECOMP3 to LCD 1 1
908 MIC_SPK CBL CSL_LCD L7 5137743 MIC and SPEAKER Cable from Front Conn2 to LCD 1 1
909 AC CABLE LCD ASSY LOGIQ7 5132394 AC Ccable from FrontConn2 to LCD 1 1
- LCD ARM LCD L7 5132571
Arm assy includes covers (911 and 912). Obsolete,
Replaced by 5132571-2. Do NOT use this parts!
- -
- LCD ARM LCD L7 5132571-2
Arm assy includes covers (911 and 912). Obsolete.
Use FRU 5264730 to upgrade this part to -4 if stock
remains.
- -
- LCD ARM LCD L7 5132571-3
Arm assy includes covers (911 and 912). Obsolete.
Use FRU 5264730 to upgrade this part to -4 if stock
remains.
--
910 LCD ARM LCD L7 5132571-4
Arm assy includes covers (911 and 912). Improved
rotational limiter plate. For Korea console, Arm Joint
(912(b)) must be re-used.
12
911 ARM COVER LCD L7 5136256 1 2
912 ARM JOINT COVER LCD L7 5136257
Arm plastic cover / joint. Common part between 17”
and 19” LCD Monitor arm.
1 2
912
(b)
FRU ARM JOINT COVER LCD L7 FOR
KOREA
5271234
Physically the same as 5136257, but caution label in
Korean Lanugage.
1 2
- Monitor Screws LCD L7 5137688 Special screw set used on LCD monitor 1 2
- DUAL DVI AGP 5111298
Video card for LCD monitor in BECOMP3. Obsolete,
Replaced by 5111298-2. Do NOT use this parts!
11
- DUAL DVI AGP 5111298-2 Video card for LCD monitor in BECOMP3 1 1
- PCI VGA 5121039 Video card for Touch panel in BECOMP3 1 1
