GE HEALTHCARE
DIRECTION 2286865, REVISION 14 LOGIQ™ 7 SERVICE MANUAL
Section 9-10 - Renewal Parts List for BT03 or lower 9-75
9-10-9 HDD and Battery
Figure 9-25 HDD and Battery
Table 9-48 HDD and Battery
Item Part Name Part Number Description Qty FRU
550 BECOMPSW2-SVC 2384945-3
PC Box. Refer to the table below for proper selection.
11
-
BECOMP3 SV Kit for Replacing BEP1/
BEP2
5136903
Refer to the table below for contents.
11
- CPU Battery -
Included on the CPU Board.
Type: CR2032, Lifetime: Approx. 10 years
1N
551 GLOBAL MODEM KIT 2245794 global modem (Option) 1 1
552 UPS BATTERY PACK 2304809-2 battery of ATX power supply 1 1
553 DGPCIO/VIC2-SVC 2384944
Refer to the table below for proper selection.
1 1
554 EXTENDED MEMORY2 2373707
Included in the PC box. For R3.xx (OPTION) or later
software
-2
555-
1
HDD 2304904
20GB FOR BT01
12
LEFT
550
551
552
553
554
555-1
555-2
To Next Page
