Section 9-10 - Renewal Parts List for BT03 or lower 9-79
9-10-10 Power Units (cont’d)
Table 9-49 Power Units
Item Part Name Part Number Description Qty FRU
701 SSR PANEL 2292209 including 2 SSRs and fuse 1 1
702 FUSE 2315585 F1, 200V, T12A 1 1
703 LV UNIT 2283531 low voltage regulator 1 1
703-
2
LV2 UNIT 2334197 low voltage regulator 1 1
704 HV UNIT 2372387
high voltage regulator (Half height),
including materials used when changing Full height
HV unit to the Half height.
1 1
705 AC POWER BOX 2384370 inlet unit for 100V, Including cable 1 1
705-
2
AC POWER BOX JPN 2384371 For JAPAN, inlet unit for 100V, Including cable 1 1
705-
3
AC POWER BOX 200V 2304538-4 Inlet unit for 200V 1 1
706 AC CORD 100V US 2371417 power cable of 100V, with clamp 1 1
706-
2
AC CORD 100V JPN 2371416 For JAPAN, power cable of 100V, with clamp 1 1
706-
3
AC CORD 200V EU 2371418 power cable of 200V, with clamp 1 1
706-
4
AC CORD 200V CHINA with Clamp 2379693-2 For China ONLY 1 1
708 MAIN TRANS 2373331-2 power trans 1 1
709 CONSOLE FAN ASSY 2304624 4 fans 1 1
710 BOTTOM AIR FILTER 2304172 air filter for console 1 2
711 LV FILTER 2291083 air filter for LV unit 1 2
712 MF SIDER COVER R 2284345 side cover of power supply 1 2
713 MF SIDE COVER L 2284346 side cover of power supply 1 2
- AC Cord UK & Ireland 5151455 1 2
- AC Cord Denmark 5151457 1 2
- AC Cord India & Africa 5151450 1 2
- AC Cord Australian 5151453 1 1
- AC Cord Argentina 5151454 1 1
- AC Cord Israel 5151451 1 1
- AC Cord Swiss 5151448 1 1
