Basic Operation
Menu System
19. Press the ▲ or ▼ button to select the Remote UDP Address setting.
20. Press the OK button to edit the current selection. The rst digit in the rst digit of the
address will ash.
21. Use the numeric keypad to enter the desired address.
If a one or more digits in the address is less then three digits in length, then preceding
zeros must be used to pad the value. For example, if one of the numbers is 10, then
you would enter 010 on the keypad. If the number is 5, then you would enter 005.
22. If an error is made, use the ◄ or ► to move backward or forward between each digit.
23. Press the OK button to save the change.
24. Press the ▲ or ▼ button to select the Remote UDP Port setting.
remote udp address:
_92.168.001.129
remote udp port:
50008
LAN
POE
5V DC
1 2
Matrix Controller
Status
IR
Power
Menu
1 2 3
4 5 6
7 8 9
In 0 Out Set
Clear
Mask
Preset
Back
OK
Lock
remote udp address:
192.168.1.129
OR
