Zoom20/30/35 Pro | 24Operation
4.4 Main Menu
Description The MAIN MENU is the starting place for accessing all functionality of the instrument. It is usually
displayed immediately after the Level & Plummet screen, after switching on the instrument.
MAIN MENU
Description of the MAIN MENU functions
If desired, the instrument can be configured to start in a user defined place after the Level & Plummet
screen, instead of the MAIN MENU. Refer to "6.2 Auto Start Routine".
4.5 Survey Application
Description After switching on and setting up correctly, the instrument is immediately ready for measuring.
Access Select Survey from the MAIN MENU.
SURVEY
The procedure for the quick start Survey is identical to the procedure for the application Survey available
under the Apps menu. Therefore this procedure is only described once within the application chapter.
Refer to "11.2 Survey".
Function Description
Apps To select and start applications. Refer to "11 Applications".
Data To manage jobs, data, codelists, formats, system memory and USB memory stick files.
Refer to "12 Data Management".
Settings To change EDM configurations, communication and general instrument settings. Refer
to "5 Settings".
Survey Survey program to begin measuring immediately. Refer to "4.5 Survey Application".
Transfer To export and import data. Refer to "12.2 Exporting Data".
Tools To access instrument related tools such as calibrations, personal start up settings,
licence keys and system information. Refer to "6 Tools".
CODING
To find/enter codes. Refer to "8.1 Coding".
STN
To enter station data and set the station.
Set HA
To set the horizontal direction orientation.
To Next Page
