Zoom20/30/35 Pro | 80Data Management
DATA EXPORT
Export data step-by-
step
1) Press OK in the DATA EXPORT screen after selecting the export details.
2) Select the data format and press OK or SEND.
The ASCII data format is only available for data exports to a USB memory stick, not via the RS232 serial
interface.
All jobs will be stored in the backup folder created on the USB memory stick. The job data will be stored
as individual database files for each job, which can then be imported again. Refer to "12.3 Importing Data".
Exportable job data
formats
Job data can be exported from a job in a variety of file types. A format can be defined in GGO Format
Manager. Refer to the online help of GGO for information on creating format files.
RS232 example job data output
Within the Data Type setting Observations, a data set could be shown as follows:
12.3 Importing Data
Description Data can be imported to the internal memory of the instrument via a USB memory stick.
Importable data
formats
When importing data, the instrument automatically stores the file in a directory folder based on the file
extension. The following data formats can be imported:
Access 1) Select Trans from the MAIN MENU.
2) Select Import from the DATA IMPORT & EXPORT menu.
SEARCH
To search for jobs within the internal memory.
DISPL.
To list all jobs within the internal memory.
Field Description
To USB memory stick or RS232 serial interface.
Data Type Data type to be transferred to Interface:
Observations, KnownPts or Observ. &KnownPts.
Data type to be transferred to USB-Stick:
Observations, KnownPts, Observ. &KnownPts, Road Data, Code, Format,
Configuration, Backup.
Select Job Displays the selected job file.
11....+00000D19 21..022+16641826 22..022+09635023
31..00+00006649 58..16+00000344 81..00+00003342
82..00-00005736 83..00+00000091 87..10+00001700
GSI-IDs GSI-IDs continued
11 Pt 41-49 Codes and attributes
21 Horizontal direction 51 ppm and Prism constant
22 Vertical angle 58 Prism constants
25 Orientation 81-83 (E, N, Z) Target point
31 Slope distance 84-86 (E, N, Z) Station point
32 Horizontal distance 87 Reflector height
33 Height difference 88 Instrument height
Data Type File extension Recognised as
GSI .gsi Known points
Format .frt Format file
Codelist .cls Codelist file
