Zoom20/30/35 Pro | 32Tools
6Tools
6.1 Calibration
Description The CALIBRATION menu contains tools to be used for the electronic calibration of the instrument. Using
these tools helps to maintain the measuring accuracy of the instrument.
Access 1) Select Tools from the MAIN MENU.
2) Select Calib. from the TOOLS menu.
3) Select a calibration option from the CALIBRATION screen.
Calibration options In the CALIBRATION screen there are several calibration options.
6.2 Auto Start Routine
Description Through the Auto Start tool, it is possible to record a user defined sequence of key presses so that, after
switching on the instrument, a particular screen can be displayed after the Level & Plummet screen
instead of the MAIN MENU. For example, the general SETTINGS screen for configuring the instrument
settings.
Access 1) Select Tools from the MAIN MENU.
2) Select Auto St. from the TOOLS MENU.
Auto start step-by-step 1) Press REC in the AUTO START screen.
2) Press OK to confirm the information message and begin the recording process.
3) The next key presses are stored, up to a maximum of 16. To end the recording press ESC.
4) If the auto start Status: is set to On, the stored key presses will be executed automatically after
switching on the instrument.
The automatic start routine has the same effect as pressing the keys manually. Certain instrument settings
can not be made in this way. Relative entries such as automatically setting EDM Mode: IR-Quick upon
switching on the instrument, are not possible.
6.3 System Information
Description The System information screens display instrument, system and firmware information, as well as settings
for the date and time.
Access 1) Select Tools from the MAIN MENU.
2) Select SysInfo from the TOOLS menu.
SYSTEM INFORMATION Page 1
Menu selection Description
HA-Collimation Refer to " Line-of-sight error".
Vertical Index Refer to " Vertical index error".
Comp.Index Refer to " Compensator index error".
View Adjustment
Data
Displays the current calibration values that have been set for HA-Collimation and
V-index.
Firmw.
To display details of the firmware package
installed on the instrument.
DATE
To change the date and format.
To Next Page
