Applications Zoom20/30/35 Pro | 47
11 Applications
11.1 Common Fields
Description of fields The following table describes common fields that are found within the firmware applications. These fields
are described here once and not repeated in the application chapters unless the field has a specific
meaning within that application.
11.2 Survey
Description Survey is an application used for the measurement of an unlimited number of points. It is comparable to
Survey from the MAIN MENU, but includes pre-settings for the job, station and orientation prior to begin-
ning a survey.
Access 1) Select Apps from the MAIN MENU.
2) Select SURVEY from the Apps menu.
3) Complete application pre-settings. Refer to "10 Applications - Getting Started".
SURVEY
Next step • Either, press ALL to record another point.
• Or, press ESC to exit the application.
Field Description
Pt, Pt 1 Point ID of the point.
TgtHGT Height of the reflector.
HA Horizontal direction to the point.
VA Vertical angle to the point.
hDIST Horizontal distance to the point.
sDIST Slope distance to the point.
dHGT Vertical distance to the point.
E Easting coordinate of the point.
N Northing coordinate of the point.
Z Height coordinate of the point.
I Pt
To switch between individual and current point
numbers.
CODING
To find/enter codes. Refer to "8.1 Coding".
Field Description
Comment /
Code
Comment or Code name depending on the coding method. Two coding methods are
available:
1) Comment coding: This text is stored with the corresponding measurement. The code
is not related to a codelist, it is just a simple comment. A codelist on the instrument
is not necessary.
2) Expanded coding with codelist: Press CODING. The code that was entered
is searched for within the code list and it is possible to add attributes to the code.
