Technical Data Zoom20/30/35 Pro | 93
15.5.3 Zoom30 Pro/Zoom35 Pro
Conformity to national
regulations
Frequency band 2402 - 2480 MHz
Output power
15.6 General Technical Data of the Instrument
Telescope
Compensation Quadruple axis compensation (2-axis compensator with HA-collimation and VA-Index).
Level
Control unit
Instrument Ports
* Only for Zoom30 Pro/Zoom35 Pro instruments.
• FCC Part 15 (applicable in US).
• Hereby, GeoMax AG, declares that the Zoom30 Pro/Zoom35 Pro instrument is in compliance with the
essential requirements and other relevant provisions of Directive 1999/5/EC and other applicable
European Directives. The declaration of conformity is available from GeoMax AG.
Class 1 equipment according European Directive 1999/5/EC (R&TTE) can be placed on the
market and be put into service without restrictions in any EEA Member state.
• The conformity for countries with other national regulations not covered by the FCC part 15 or Euro-
pean directive 1999/5/EC has to be approved prior to use and operation.
Bluetooth: 2.5 mW
Magnification: 30 x
Free Objective aperture: 40 mm
Focusing: 1.7 m/5.6 ft to infinity
Field of view: 1°30’/1.66 gon.
2.7m at 100m
Angular accuracy Setting accuracy Setting range
["] ["] [mgon] [’] [gon]
1 0.5 0.2 ±4 0.07
2 0.5 0.2 ±4 0.07
310.3±40.07
5 1.5 0.5 ±4 0.07
720.7±40.07
Circular level sensitivity: 6’/2 mm
Electronic level resolution: 2"
B&W display: 288 x 160 pixels, LCD, backlit, 8 lines with 31 characters each, heatable (temp.
<-5°).
C&T display: 320 x 240 pixels (QVGA), LCD, backlit, 9 lines with 31 characters each, keyboard
illumination
Name Description
Serial/USB 6 pin Hiroshi for power, communication, data transfer.
This port is located at the base of the instrument.
USB host port USB memory stick port for data transfer.
Bluetooth* Bluetooth connections for communication and data transfer.
