Zoom20/30/35 Pro | 38Functions
Access 1) Press FNC when within any application.
2) Select Brg/Dist from the FUNCTIONS menu.
CONTROL DISTANCE
Messages The following are important messages or warnings that may appear.
Next step Press OK to return to the application where FNC was selected.
7.7 EDM Continuous
Description This function activates or deactivates the tracking measurement mode. The new setting is displayed for
about one second and then set. The function can only be activated from within the same EDM mode and
prism type. The following options are available.
The last active measurement mode remains set when the instrument is switched off.
Field Description
Brg Difference in bearing between the two points.
Grade Difference in gradient between the two points.
hDIST Difference in horizontal distance between the two points.
sDIST Difference in slope distance between the two points.
d.d.Z Difference in height between the two points.
Messages Description
Less than two valid measure-
ments!
The values cannot be calculated as there are less than two valid meas-
urements.
Mode Off <=> On
IR IR-Default <=> IR-Continuous / IR-Quick <=> IR-Continuous.
RL RL-Default <=> RL-Continuous.
