16-2 16. MITSUBISHI ELECTRIC PLC
A Series CPU, QnA Series CPU, QnH Series CPU, Q00J/00/01 CPU
FX Series
*1 For more information of V-MDD (dual port interface), refer to page 16-15.
*2 For the ladder transfer function used when directly connecting the QnH series CPU, refer to page 16-15.
*3 For connection to MJ2 of a V706, use an MJ2-PLC adaptor plus QCPU2.
Select PLC Type CPU Unit/Port Connection PLC2Way
A series CPU
A2A, A3A
A2U, A3U, A4U
A2US(H)
A1N, A2N, A3N
A3V, A73
A3H, A3M
A0J2H
A1S(H), A1SJ(H), A2S(H)
A2CCPUC24
A1FX
Tool port
*1
RS-422
Hakko Electronics’ cable
“MB-CPUQ”
or
[Wiring Diagram 7]
QnA series CPU
Q2A, Q3A, Q4A
Q2AS(H)
QnH (A) series CPU Q06H-A Tool port
RS-232C
Hakko Electronics’ cable
“QCPU2”
*3
QnH (Q) series
CPU
Q02, Q02H
Q06H
Q12H
Q25H
Tool port
*2
Q00J/00/01 CPU
Q00J
Q00
Q01
Tool port
Select PLC Type CPU Unit/Port Connection PLC2Way
FX series CPU
FX1/2
Tool port
*1
RS-232C
Hakko Electronics’ cable
“PC-CX24A”
RS-422
Hakko Electronics’ cable
“MB-CPUQ”
or
[Wiring Diagram 7]
FX0N
Tool port
*1
RS-422
Hakko Electronics’ cable
“MI4-FX”
*2
or
Hakko Electronics’ cable
“MB-CPUQ”
+
MITSUBISHI’s conversion
cable “FX-20P-CADP”
FX2N series CPU
FX2N/1N
FX2NC
FX1S series CPU FX1S
FX series link
(A Protocol)
FX2N
FX2N-232-BD
RS-232C [Wiring Diagram 3]
FX2N-485-BD
RS-485 [Wiring Diagram 8]
FX2N-422-BD
RS-422 Hakko Electronics’
cable “MI4-FX”
*2
FX1N
FX1S
FX1N-232-BD
RS-232C [Wiring Diagram 3]
FX1N-485-BD
RS-485 [Wiring Diagram 8]
FX1N-422-BD
RS-422 Hakko Electronics’
cable “MI4-FX”
*2
FX0N
FX0N-232ADP
RS-232C [Wiring Diagram 4]
FX0N-485ADP
RS-485 [Wiring Diagram 8]
FX2NC
FX0N-232ADP
RS-232C [Wiring Diagram 4]
FX0N-485ADP
RS-485 [Wiring Diagram 8]
