7. FATEK AUTOMATION PLC 7-1
7. FATEK AUTOMATION PLC
Available PLCs
Communication Setting
The recommended communication parameter settings of the PLC and the V7 series are as follows:
Available Memory
The available memory setting range varies depending on the PLC model. Be sure to set within the
range available with the PLC to be used. Use [TYPE] when assigning the indirect memory for macro
programs.
Select PLC Type PLC Unit/Port Connection
FACON FB series FACON FB series FB-DTBR
RS-232 [Wiring Diagram 1]
[Wiring Diagram 2]
RS-422 [Wiring Diagram 3]
Item Setting on PLC V7 Comm. Parameter Setting
Baud rate 9600 bps 9600 bps
Parity Even (fixed) −
Transmission
code
Data length 7 (fixed) −
Stop bit 1 (fixed) −
Memory TYPE Remarks
HR (data register) 0
DR (data register) 1
X (input relay) 2
Y (output relay) 3
M (internal relay) 4
S (step relay) 5
T (timer contact) 6 Read only
C (counter contact) 7 Read only
RT (timer/current value) 8
RC (counter/current value) 9
DRC (32-bit counter/current value) 10
