12-2 12. KEYENCE PLC
Communication Setting
The recommended communication parameter settings of the PLC and the V7 series are as follows:
KZ Series Link
Set the port with the port setting switch, the terminating resistance with terminator, and the baud
rate/data bit/parity/stop bit with SET B DIP switches.
KZ-A500 CPU (CPU Modular Port)
*1 For signal level RS-422, baud rate is fixed to 9600 bps.
MITSUBISHI A Series Link (Link Unit KZ-L10)
Set the port with the port setting switch, the terminating resistance with terminator, and the baud rate/
data bit/parity/stop bit with SET B DIP switches.
For more information, refer to the instruction manual for KZ-L10.
KZ/KV Series CPU
Communication parameters for the V7 series are automatically set.
Item Setting on PLC V7 Comm. Parameter Setting
Port 0 0
Baud rate 19200 bps 19200 bps
Parity Even Even
Transmission
code
Data length 7 (ASCII) 7
Stop bit 2 2
Terminating resistance ON for RS-422 −
Operation mode Link mode −
Item Setting on PLC V7 Comm. Parameter Setting
Port 0 0
Baud rate 9600 bps
9600 bps
*1
Parity Odd Odd
Transmission
code
Data length 8 8
Stop bit 1 1
Terminating resistance ON for RS-422 −
Item Setting on PLC V7 Comm. Parameter Setting
Port 0 0
Baud rate 19200 bps 19200 bps
Parity Even Even
Transmission
code
Data length 7 7
Stop bit 1 1
Sumcheck Provided (fixed) −
Terminating resistance ON for RS-422 −
Communication type Normal communication −
Transmission mode Protocol code 1 Trans. Mode 1
