27-2 27. TOSHIBA PLC
Available Memory
The available memory setting range varies depending on the PLC model. Be sure to set within the
range available with the PLC to be used. Use [TYPE] when assigning the indirect memory for macro
programs.
T Series
EX Series
Memory TYPE Remarks
D (data register) 0
X (input) 1 XW as word device
Y (output) 2 YW as word device
R (auxiliary relay) 5 RW as word device
L (link relay) 6 LW as word device
W (link register) 7
F (file register) 8
TN (timer/current value) 9 Read only
CN (counter/current value) 10 Read only
TS (timer/contact) 11 Read only
CS (counter/contact) 12 Read only
Memory TYPE Remarks
D (data register) 0
X (input) 1 XW as word device
Y (output) 2 YW as word device
R (auxiliary relay) 3 RW as word device
Z (link relay) 4 SW as word device
TN (timer/current value) 5 Read only
CN (counter/current value) 6 Read only
