22. SHARP PLC 22-1
22. SHARP PLC
Available PLCs
Communication Setting
The recommended communication parameter settings of the PLC and the V7 series are as follows:
JW Series: Link Unit Switch Setting
Baud rate: 19200 bps
Select PLC Type CPU Unit/Port Connection PLC2Way
JW series
JW50, JW70, JW100
JW50H, JW70H
JW100H
ZW-10CM
JW-10CM
RS-422 [Wiring Diagram 4]
JW20
JW-31CUH
JW-21CM RS-422 [Wiring Diagram 4]
JW100/70H
COM port
JW70CU/JW100CU
JW70CUH, JW100CUH
Communication port on the
CPU unit
RS-232C [Wiring Diagram 1]
JW20
COM port
JW22CU RS-422 [Wiring Diagram 3]
JW-32CUH
JW-33CUH
Communication port 1 on the
CPU unit
Communication port 2 on the
CPU unit
RS-232C
PG/COMM2
[Wiring Diagram 2]
RS-422
PG/COMM1
[Wiring Diagram 5]
PG/COMM2
[Wiring Diagram 5]
Item Setting on PLC V7 Comm. Parameter Setting
Baud rate 19200 bps 19200 bps
Port 0 for STA. NO ×10, 1 for STA. NO ×11
Parity Even Even
RS-422 4-wire system (fixed) −
Data length 7 7
Stop bit 2 2
Error check Sumcheck (fixed) −
Transmission mode Command mode (fixed) −
Switch Setting Contents
SW0 4 Command mode
SW1 1 Station address (lower half)
SW2 0 Station address (upper half)
SW3-1 OFF Not used
SW3-2 ON 4-wire system
SW3-3 OFF Not used
SW3-4 ON Even parity
SW4 0
Baud rate
0: 19200 1: 9600 2: 4800 3: 2400 4: 1200 5: 600
SW7 ON Terminating resistance provided
