4-2 4. Baldor PLC
Wiring
Wiring diagram with the PLC is shown below.
RS-232C
Wiring Diagram 1
PLC
RXD
TXD
DTR
SG
2
3
4
5
DSR
RTS
CTS
6
7
8
1
2
3
SD
RD
SHELL
8
7
*1
7SG
5
* Use shielded twist-pair cables.
D-sub 9-pin (female)
D-sub 25-pin (male)RJ-45 8-pin
V Series
CN1
V706
MJ2
*1 Pin No. 1 of CN1 is used
as FG.
The metal shell of the
modular jack 2 on the
V706 is used as SG.
