12-4 12. KEYENCE PLC
Available Memory
The available memory setting range varies depending on the PLC model. Be sure to set within the
range available with the PLC to be used. Use [TYPE] when assigning the indirect memory for macro
programs.
KZ Series Link
KZ-A500 CPU, MITSUBISHI A Series Link
KZ/KV Series CPU, KZ24/300 CPU, KV10/24 CPU, KV-700 CPU
Memory TYPE Remarks
DM (data memory) 0
CH (input/output relay) 1
Memory TYPE Remarks
D (data register) 0
W (link register) 1
R (file register) 2
TN (timer/current value) 3
CN (counter/current value) 4
M (internal relay) 6
L (latch relay) 7
B (link relay) 8
X (input relay) 9
Y (output relay) 10
TS (timer/contact) 11
TC (timer/coil) 12
CS (counter/contact) 13
CC (counter/coil) 14
Memory TYPE Remarks
DM (data memory) 0
CH (input/output relay) 1
TC (timer/current value) 2
CC (counter/current value) 3
TS (timer/set value) 4
CS (counter/set value) 5
T (timer/contact) 6
C (counter/contact) 7
TM (temporary data memory) 8
CTH (high-speed counter/current value) 9 KV700 only
CTC
(high-speed counter comparator/setting
value)
10 KV700 only
CT (high-speed counter comparator/contact) 11 KV700 only
CR (control relay) 12 KV700 only
CM (control relay) 13 KV700 only
To Next Page
