8. Fuji Electric PLC 8-1
8. Fuji Electric PLC
Available PLCs
*1 To use FLEX-PC of Toyota version, select [FLEX-PC (T)].
*2 To use FLEX-PC CPU of Toyota version, select [FLEX-PC CPU (T)].
*3 For connection to MJ2 of a V706, use an MJ2-PLC adaptor plus FU-CPUNS.
Communication Setting
The recommended communication parameter settings of the PLC and the V7 series are as follows:
MICREX-F Series, SPB (N Mode) & FLEX-PC Series
SPB (N Mode) & FLEX-PC CPU Port
Connect to the CPU port. Communication parameters for the V7 series are automatically set.
Select PLC Type PLC Unit/Port Connection PLC2Way
MICREX-F series
(MICREX-F series
V4)
F55 NV1L-RS2
RS-232C [Wiring Diagram 1]
F70, F70S
NC1L-RS2
RS-232C [Wiring Diagram 1]
NC1L-RS4
RS-485 [Wiring Diagram 3]
F80H, F120H, F120S
F140S, F15 S
FFU120B
RS-232C [Wiring Diagram 1]
FFK120A
RS-485 [Wiring Diagram 3]
SPB (N Mode) &
FLEX-PC series
*1
NS-T NJRS-1
RS-232C [Wiring Diagram 1]
NJ-T
NJRS-2
RS-232C [Wiring Diagram 1]
NJRS-4
RS-485 [Wiring Diagram 3]
SPB (N Mode) &
FLEX-PC CPU
*2
FLEX-PC CPU port
RS-485
Hakko Electronics’ cable
“FU-CPUNS”
*3
NJ-B16 RS-232C port
RS-232C [Wiring Diagram 2]
FLEX-PC COM(T) FLEX-PC NJ-JM Computer link terminal block
RS-422 [Wiring Diagram 4]
Item Setting on PLC V7 Comm. Parameter Setting
Baud rate 19200 bps 19200 bps
Port 0 0
Parity Even Even
Transmission
mode
RS-232C
1 (asynchronous non-protocol by
command) (fixed)
−
RS-422
3 (asynchronous non-protocol by
command) (fixed)
−
Transmission
code
Data length 7 (ASCII) 7
Stop bit 1 1
Terminating resistance at
receiver
Provided for RS-485 −
