4. Baldor PLC 4-1
4. Baldor PLC
Available PLCs
Communication Setting
The recommended communication parameter settings of the PLC and the V7 series are as follows:
Available Memory
The available memory setting range varies depending on the PLC model. Be sure to set within the
range available with the PLC to be used. Use [TYPE] when assigning the indirect memory for macro
programs.
Select PLC Type Unit/Port Connection
Mint
NextMove (Comms Data Array)
RS-232C [Wiring Diagram 1]
Optimum (Comms Data Array)
Item Setting on PLC V7 Comm. Parameter Setting
Baud rate 9600 bps 9600 bps
Port 0 0
Parity None None
Transmission
code
Data length 8 8
Stop bit 1 1
Memory TYPE Remarks
I (Integer) 0
F (Float) 1
B (Integer omitting decimals) 2
