App5-28 Appendix 5 Ethernet
Ethernet Access Functions (HKEtn10.DLL)
To enable Ethernet communications between the server and the V7 series, it is necessary to create an
application based on HKEtn10.dll (for UDP/IP) provided by us, using Visual C++, Visual Basic, etc.
Sample Folder
The “Sample” folder for Ethernet communications is included in the V-SFT CD-ROM.
The [Ethernet] folder contains sample programs created using Visual C++, and the [VBA] folder
contains those created using VBA.
Refer to these sample program when creating an application. If necessary, you can copy and tailor the
program to your requirements.
• Ethernet
The following files are contained in the respective folders.
[Ethernet]
- ESmpl.dsp - ESmpl.h - ESmpl.cpp - ESmpl.rc
- ESmpl.clw - MainFrm.h - MainFrm.cpp - ESmplDoc.h
- ESmplDoc.cpp - ESmplView.h - ESmplView.cpp - StdAfx.h
- StdAfx.cpp - Resource.h - ReadMe.txt - HKEtn10.h
[Release]
- HKEtn10.dll - HKEtn10.lib
[res]
- ESmpl.ico - ESmpl.rc2 - Toolbar.bmp - ESmplDoc.ico
• VBA
The following files are contained in this folder.
[VBA]
- HKEtn10.dll
- VBA_Sample.xls
* To execute this program, copy the above files to the “C:\TEST” folder.
Port No. 10000 is set.
When changing the copy target or the port number, change the setting in the program
accordingly.
V-SFT CD-ROM
Sample Eng
Ethernet
Release
Res
VBA
Jpn
To Next Page
