28. TOSHIBA MACHINE PLC 28-1
28. TOSHIBA MACHINE PLC
Available PLCs
Communication Setting
The recommended communication parameter settings of the PLC and the V7 series are as follows:
Available Memory
The available memory setting range varies depending on the PLC model. Be sure to set within the
range available with the PLC to be used. Use [TYPE] when assigning the indirect memory for macro
programs.
Select PLC Type PLC Unit/Port Connection
TC200
TC200
Port on the CPU unit
RS-232C [Wiring Diagram 1]
TCCMW
TCCMO
TCmini −
Item Setting on PLC V7 Comm. Parameter Setting
Baud rate 9600 bps 9600 bps
Port 1 1
Parity Not provided None (fixed)
Transmission
code
Data length 8 8 (fixed)
Stop bit 2 2
Memory TYPE Remarks
D (register 1) 0
B (register 2) 1
X (input relay) 2 XW as word device
Y (output relay) 3 YW as word device
R (temporary storage) 4 RW as word device
G (extension temporary storage 1) 5 GW as word device
H (extension temporary storage 2) 6 HW as word device
L (latch relay) 7 LW as word device
S (shift register) 8 SW as word device
E (edge relay) 9 EW as word device
P (timer counter current value) 10
V (timer counter set value) 11
T (timer) 12 TW as word device
C (counter) 13 CW as word device
A (special auxiliary relay) 14 AW as word device
